Big Bale Transporter

Big Bale Transporter

Product Ref: BBT


Price £1,615.00 + VAT

Top of Form 1

Bottom of Form 1

Details and Specification

This unit will pick up a large bale ready to be transported to the required site. The large low ground pressure wheels will allow the unit to be towed over unfriendly ground.

Method of Operation

Remove the trailer floor
Reverse the trailer over the bale
Lift bale and secure
Replace floor


Overall width 2000mm (80")
Overall length (inc tow bar) 2400mm (96")
Unladen weight 200kg
Carrying Capacity 1000kg
Wheels 20x10-8.4 stud pneumatic
Lifting jib Hydraulic manual pump
Tow hitch 50mm Ball hitch
